Phoenix Edge Lite 75: 25V 75-Amp Brushless ESC (CSE010011200)

The Phoenix Edge Lite 75 is a 25V 75-Amp Brushless ESC designed to elevate your RC experience with advanced technology and exceptional versatility. This state-of-the-art speed controller features a user-programmable auxiliary wire that can be utilized for various functions, such as mid-flight helicopter governor gain input adjustments, acting as an audible beacon post-landing, and providing RPM output for compatible 3-axis gyros. The ESC also acts as an arming lock for enhanced safety, ensuring your setup functions optimally.

This model includes data logging capabilities, allowing users to monitor and analyze recorded ESC data through the Castle Link USB adapter and Castle Link Windows software. With power system alerts programmed to inform users of issues such as over-temperature and excessive load through motor sounds and LED flashing patterns, this ESC promotes both performance and safety.

The Phoenix Edge Lite 75 is equipped with AUX functionality, permitting additional tasks such as serving as an ESC arming lock or a receiver arming lock, depending on the configuration. Its telemetry capabilities enhance safety further by monitoring critical parameters like battery voltage and ESC temperature, alerting users to potential issues and thereby minimizing the risks of crashes.

Additional features include protection through an Arm Lock Key, ensuring the ESC will not arm when inserted, and full programmability with the Castle Link USB adapter, allowing for extensive customization of settings. Users are also provided free access to firmware updates, ensuring that functionality remains up-to-date and effective.

Overall, the Phoenix Edge Lite 75 Brushless ESC is an ideal choice for those looking to increase their RC performance while maintaining complete control and safety during operation.
