1512/2650KV V2 Sensored Brushless Motor (CSE060-0114-00)

The 1512/2650KV V2 sensored brushless motor is a compact, high‑performance powerplant for RC vehicles. It runs on 2S–4S LiPo packs and uses sensor feedback to deliver smooth starts, reduced cogging, and efficient, reliable torque. It’s well suited for 1/8-scale off‑road and on‑road models as well as 1/10-scale 4WD SCTs up to nine pounds.

Built around a redesigned rotor and stator, it features Kevlar wrap and 180°C magnets for strength and heat resistance, plus a 0.2mm steel-lamination stator for efficiency. The assembly uses 10 AWG, high-strand silicone-insulated wiring with 6.5mm bullet connectors, oversized gold-plated solder tabs, and a sensor board with temperature-stabilized sensors. CNC-machined T6 aluminum end bells cap the design, with oversized NMB bearings and high-temperature, high-purity copper windings for durability. The motor is rebuildable, allowing replacement of the front-end bell/bearing or rotor/shaft as needed.
